Four Post Cargo Lift

Four Post Cargo Lift is a non scissor hydraulic lift platform used for transporting goods in industrial plants, restaurants, and eateries with two or more floors. Small spaces that are difficult to solve, such as those between high-rise buildings on the second floor or above, areas where it is impossible to excavate pits, and situations where the top floor height cannot reach the required level. Due to its minimum height of only 150-300mm, it is used in workplaces where excavation of pits is not possible, and there is no need for upper adjustment points. It has various forms (single column, double column, four column), smooth operation, simple and reliable operation, and economical and easy transportation of hydraulic and electrical goods. (Specific bearing capacity, number of raised layers, and size can be designed and manufactured according to user requirements)

Ideal for 2-6 story steel or concrete structures, both indoors and outdoors. Connect floor doors for convenient access between interior and exterior areas. Suitable for:

• Industrial plants
• Warehouses
• Restaurants and eateries
• Commercial buildings
• Parking garages (connecting upper floors and underground levels)

Key Features and Benefits:

• Space Optimization: Minimal pit depth (150-300mm) and no overhead machine room required, maximizing usable space and simplifying installation in existing buildings.
• High Load Capacity: Handles loads up to 15 tons, suitable for a wide range of materials and equipment.
• Customizable Configurations: Available in single, double, and four-column configurations to meet specific site requirements. Customizable platform sizes, lifting heights, and load capacities are available upon request.
• Smooth and Reliable Operation: Imported pump stations, oil cylinders, and seals ensure smooth, quiet, and dependable performance. Customized pump stations are available for higher speed requirements.
• Advanced Safety Features:
  • Emergency Manual Descent: Safe lowering during power outages.
  • Overload Protection: Prevents operation beyond the rated capacity.
  • Pipeline Rupture Valve: Prevents uncontrolled descent in case of hydraulic line failure.
  • Oil Tank Temperature Protection: Prevents overheating and extends system lifespan.
  • Interlocking Doors: Ensures safe loading and unloading at each level.
• Easy Installation and Maintenance: Simple design and robust construction minimize installation time and reduce maintenance needs.
• Cost-Effective Solution: A practical and economical alternative to traditional elevators for low-to-mid-rise applications.
