Introduction
Aluminum alloy Lifting Platform adopt new type of high strength aluminum alloy profiles, the elevator, stable lifting , the deflection of the appearance of small, light and beautiful, mobile and flexible, can be made into a vehicle-mounted, down type according to the requirement, the title and single column, double mast, three mast and other products, widely used in hotel, bank, hall, supermarkets and other places.The rated lifting capacity of a single mast is 100kg and its lifting height is 6~10m. The rated lifting capacity of a double mast is 200kg and its lifting height is 8~18m.
Application
Aluminum alloy lift aerial work platform is ideal for a wide range of applications, including maintenance, cleaning, and installation tasks in factories, hotels, airports, and stadiums. It can be used to access hard-to-reach areas, such as high ceilings, skylights, and signage, ensuring efficient and safe operations.
Features
General Features:
- Lightweight and Maneuverable: Made with a strong aluminum mast, offering smooth lifting and easy movement.
- Platform Control: Allows workers to control platform elevation with an emergency stop button for safety.
- Safety Systems: Includes leakage protection, thermal protection, and emergency travel protection for added security.
- Power Failure Safeguards: Features self-locking upon power failure, emergency descent, and cylinder crack prevention.
- Compact Design: Can access narrow spaces like elevators and doorways.
- Lightweight and Strong Mast: High-strength aluminum alloy offers both durability and weight reduction.
- Minimized Dynamic Clearance: Uses self-developed integral sliders for smoother and more stable operation.
- Superior Stability: Delivers better performance compared to lifts with independent guide wheels.
Parameter
Name | Model | Maxi.platform height (m) | Rated load capacity (kg) | Platform size (m) | power(kW) | Total weight (kg) | Overall size (m) |
Single mast | GTWY4-1 | 4 | 100 | 0.6*0.6 | 1.1 | 280 | 1.3*0.8*1.98 |
GTWY6-1 | 6 | 150 | 0.65*0.65 | 1.1 | 360 | 1.42*0.78*1.97 | |
GTWY8-1 | 8 | 130 | 0.65*0.65 | 1.1 | 380 | 1.42*0.78*1.97 | |
GTWY10-1 | 10 | 130 | 0.65*0.65 | 1.1 | 420 | 1.42*0.78*1.97 | |
Double mast | GTWY6-2 | 4 | 300 | 1.2*0.63 | 1.5 | 510 | 1.55*0.85*2.0 |
GTWY8-2 | 8 | 300 | 1.2*0.63 | 1.5 | 550 | 1.55*0.85*2.0 | |
GTWY10-2 | 10 | 250 | 1.5*0.63 | 1.5 | 690 | 1.84*0.85*2.0 | |
GTWY12-2 | 12 | 200 | 1.5*0.63 | 1.5 | 730 | 1.84*0.85*2.0 | |
GTWY14-2 | 14 | 150 | 1.5*0.63 | 1.5 | 790 | 1.95*1.05*2.39 | |
Three mast | GTWY12-3 | 12 | 200 | 1.57*0.9 | 2.2 | 1050 | 1.9*1.1*1.98 |
GTWY14-3 | 14 | 200 | 1.57*0.9 2 | 2.2 | 1120 | 1.9*1.2*2.3 | |
GTWY16-3 | 16 | 200 | 1.57*0.9 2 | 2.2 | 1200 | 2.0*1.2*2.7 | |
Four mast | GTWY12-4 | 12 | 200 | 1.57*0.9 | 2.2 | 1050 | 1.9*1.2*2.0 |
GTWY14-4 | 14 | 200 | 1.57*0.9 | 2.2 | 1150 | 1.9*1.2*2.3 | |
GTWY10-4 | 16 | 200 | 1.57*0.9 | 2.2 | 1250 | 1.9*1.2*2.7. | |
GTWY18-4 | 18 | 200 | 1.57*0.9 | 2.2 | 1480 | 2.0*1.4*2.96 | |
Standard voltage is 220V 50HZ 1 phase , The voltage can be customized according to different country | |||||||
Optional configuration | |||||||
*battery +AC power for platform raise and down | *Assistant move system | ||||||
Part Detail
Travel switch DELIXI brand
